· Up to 2592x1944@20fps
· S+265/H.265/H.264
· Min. illumination Color: [email protected]
· 120dB WDR
· Smart IR, IR Range: 30m
· Support tripwire and perimeter
· Built-in Mic, SD Card Slot, Reset Button
· Operating Conditions -35°~65°, 0~95% RH
· POE, IP67
Specification
|
Camera |
|
|
Image Sensor |
1/2.8" CMOS |
|
Signal System |
PAL/NTSC |
|
Min. Illumination |
Color:0.002Lux@(F1.6,AGC ON),B/W:0Lux with IR |
|
Shutter Time |
1s to 1/100,000s |
|
Day & Night |
Dual IR Cut Filter with Auto Switch |
|
WDR |
120dB |
|
Angle Adjustment |
pan 0~340°,tilt 0~75°,roate 0~360° |
|
Lens |
|
|
Lens Type |
Fixed |
|
Focus |
2.8mm |
|
Lens Mount |
M12 |
|
Aperture |
F1.6,Fixed |
|
FOV |
Horizontal field of view:94.7°；Vertical field of view:71.2° |
|
Illuminator |
|
|
IR LEDs |
2 |
|
IR Range |
Up to 30m |
|
Wavelength |
850nm |
|
White LEDs/Warmlights |
N/A |
|
Compression Standard |
|
|
Video Compression |
S+265/H.265/H.264 |
|
Video Bit Rate |
32Kbps~6Mbps |
|
Audio Compression |
G.711A/G.711U/ADPCM_D |
|
Audio Bit Rate |
8K,32K,48Kbps |
|
Image |
|
|
Max. Resolution |
2592x1944 |
|
Main Stream |
PAL:20fps(2592x1944,2592x1520),25fps(2560x1440,2304x1296,1920x1080,1280x720) |
|
NTSC:20fps(2592x1944,2592x1520),25fps(2560x1440),30fps(2304x1296,1920x1080,1280x720) |
|
|
Sub Stream |
PAL:25fps(704x576,704x288,640x360,352x288) |
|
NTSC:30fps(704x480,704x240,640x360,352x240) |
|
|
Third Stream |
N/A |
|
Image Setting |
Saturation,brightness,contrast,sharpness,adjustable by client software or web browser |
|
Image Enhancement |
BLC/3D DNR/HLC |
|
ROI |
N/A |
|
OSD |
16x16,32x32,48x48,adaptable size,Letters Such as Week,Date,Time,Total 1 Regions |
|
Picture Overlay |
N/A |
|
Privacy Mask |
Yes,4 regions |
|
Smart Defog |
Yes |
|
Feature |
|
|
Alarm Trigger |
Motion Detection,Mask Alarm,IP Address Conflict |
|
Video Analytics |
Tripwire,Perimeter |
|
Early Warning(EW) |
N/A |
|
Network |
|
|
ANR |
Yes(Only Support Tiandy ANR NVR) |
|
Protocols |
HTTP,TCP/IP,ICMP,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,UPnP,UDP |
|
System Compatibility |
ONVIF(PROFILE S/T/G),SDK,CGI,Milestone,P2P(Mutually exclusive with Profile G) |
|
Remote Connection |
2 |
|
Client |
Easy7,EasyLive |
|
Web Version |
Web6 |
|
Interface |
|
|
Communication Interface |
1 RJ45 10M/ 100M self adaptive Ethernet port |
|
Audio I/O |
Mic in |
|
Alarm I/O |
N/A |
|
Speaker |
N/A |
|
Reset Button |
Yes |
|
On-board storage |
Built-in MicroSD card slot,up to 512 GB |
|
General |
|
|
Web Client Language |
17 languages |
|
Operating Conditions |
-35℃～60℃,0～95% RH |
|
Power Supply |
DC 12V±25%,PoE(802.3af) |
|
Power Consumption |
MAX:6W(12V) MAX:8W(PoE) |
|
Protection |
IP67 |
|
Heater |
N/A |
|
Dimensions |
116.6 83.7mm( 4.59 3.30inch) |
|
GrossWeight |
Metal+Plastic:0.51Kg(1.12lb) Metal:0.64Kg(1.41lb) |
|
NetWeight |
Metal+Plastic:0.34Kg(0.75lb) Metal:0.47Kg(1.03lb) |
