• Metal+Plastic Housing
• Up to 1920x1080@30fps
• S+265/H.265/H.264
• Min. illumination Color: [email protected]
• Smart IR, IR Range: 50m
• Operating Conditions -35℃~65°C, 0~95% RH
• Built-in Mic, SD Card Slot, Reset Button
• Support Wi-Fi
• P67
Specification
|
Camera |
|
|
Image Sensor |
1/2.8" CMOS |
|
Signal System |
PAL/NTSC |
|
Min. Illumination |
Color: 0.02Lux@ (F2.0, AGC ON), B/W: 0Lux with IR |
|
Shutter Time |
1s to 1/100,000s |
|
Day & Night |
Dual IR Cut Filter with Auto Switch |
|
Wide Dynamic Range |
Digital WDR |
|
Angle Adjustment |
Bracket, pan 0~360°, tilt 0~75°, roate 0~360° |
|
Lens |
|
|
Lens Type |
Fixed |
|
Focus |
4mm |
|
Lens Mount |
M12 |
|
Aperture |
F2.0, Fixed |
|
FOV |
Horizontal field of view: 83.3° Vertical field of view: 46.8° |
|
Illuminator |
|
|
IR LEDs |
2 |
|
IR Range |
Up to 50m |
|
Wavelength |
850nm |
|
White LEDs |
N/A |
|
Compression Standard |
|
|
Video Compression |
S+265/H.265/H.264 |
|
Video Bit Rate |
32Kbps~6Mbps |
|
Audio Compression |
G.711/G.711U/ADPCM |
|
Audio Bit Rate |
8K~48Kbps |
|
Image |
|
|
Max. Resolution |
1920x1080 |
|
Main Stream |
PAL: 25fps (1920×1080, 1280×720, 704×576, 640×480) |
|
NTSC: 30fps (1920×1080, 1280×720, 704×480, 640×480) |
|
|
Sub Stream |
PAL: 25fps (704×576, 704×288, 640×360, 352×288) |
|
NTSC: 30fps (704×480, 704×240, 640×360, 352×240) |
|
|
Third Stream |
N/A |
|
Image Setting |
Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
|
Image Enhancement |
BLC/3D DNR/HLC |
|
ROI |
N/A |
|
OSD |
16x16, 32x32, adaptable size, Letters Such as Week, Date, Time, Total 1 Regions |
|
Picture Overlay |
N/A |
|
Privacy Mask |
Yes, 4 regions |
|
Smart Defog |
Yes |
|
Feature |
|
|
Alarm Trigger |
Motion Detection, Mask Alarm, IP Address Conflict |
|
Video Analytics |
Tripwire, Perimeter |
|
Early Warning(EW) |
N/A |
|
Network |
|
|
Network Storage |
Yes(Only Support Tiandy ANR NVR) |
|
Protocols |
TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, IPV4, NTP, UDP, Telnet, ICMP, RTP, RTSP, UPnP |
|
System Compatibility |
ONVIF(PROFILE S/T/G),SDK,CGI,Milestone,P2P(Mutually exclusive with Profile G) |
|
Remote Connection |
2 |
|
Client |
Easy7, EasyLive |
|
Web Version |
Web6 |
|
Wi-Fi |
|
|
Wireless Standards |
IEEE802.11b/g/n |
|
Frequency Range |
2.4GHz ~ 2.4835 GHz |
|
Channel Bandwidth |
20/40MHz |
|
Protocols |
802.11b: CCK, QPSK, BPSK |
|
Security |
WPA-PSK/WPA2-PSK |
|
Transfer Rates |
802.11b: 11Mbps |
|
Wireless Range |
Up to 50m (The performance varies based on actual environment) |
|
Power Consumption |
802.11b: 17±1.5dBm@11Mbps |
|
Interface |
|
|
Communication Interface |
1 RJ45 10M/ 100M self adaptive Ethernet port |
|
Audio I/O |
Mic in |
|
Alarm I/O |
N/A |
|
Reset Button |
Yes |
|
On-board storage |
Built-in MicroSD card slot, up to 512 GB |
|
General |
|
|
Web Client Language |
17 languages |
|
Operating Conditions |
-35℃～65℃, 0～95% RH |
|
Power Supply |
DC 12V±25% |
|
Power Consumption |
MAX: 6.8W(12V) |
|
Protection |
IP67 |
|
Heater |
N/A |
|
Dimensions |
161mm×68mm×66mm (6.34×2.68×2.60 inch) |
|
Weight |
0.31Kg (0.68lb) |
