Battery-powered Video Doorbell Kit
Know who’s at your doorstep and why, even before they ring the bell. The EZVIZ DB2 Pro features ultra-sharp 2K+ resolution, wide field-of-view, large battery capacity, and extremely easy installation. It’s the new go-to security option for any apartment dweller or villa owner.
5MP resolution
Smart Human Motion Detection
176º Ulta-wide field of view
5,200 mAh rechargable lithium battery
Wi-Fi chime included (supports microSD card upto 256GB)
Multiple ringtones available
IR night vision (up to 5m/6ft)
Anti-Tamper alarm
Weatherproof design
H.265 video technology
Clear, vivid view with EZVIZ’s first 2K+ video doorbell.
Featuring the top resolution of its kind, the DB2 Pro renders crisp, clear video to capture every vivid detail of the visitors, and provides 5-meter infrared night vision for 24/7 protection
A well-thought-out solution in one kit.
To make sure you hear the ring even from afar, EZVIZ pairs it with an indoor chime. What’s better, the chime can help extend your Wi-Fi signal, and boost the network for the doorbell to ensure it get connected stably – which many wireless doorbells may struggle with.
Set up in minutes, and use for about 4 months.
If you are less than a stellar electrician, this wireless, wire-free and weatherproof DB2 Pro could be your best option – stick it anywhere and enjoy long-lasting performance.
See ultra-wide to get the whole picture.
With a 176-degree viewing angle, you can easily see the postman from head to toe and know where he places your package. The doorbell also comes with several different mounting plates in the package, which can help adjust the angle of installation to optimize the doorbell’s vision.
A smart doorkeeper to keep you in the know
With both human-shape and PIR detection capabilities, the device is smart enough to distinguish people from pets or objects. You can customize the alert trigger conditions to adjust its sensibility.
*The suggested PIR detection distance comes from EZVIZ Lab’s test results. May vary based on different environmental factors
Talk, before you get the door
Answer before you get the door for friends or deliveries! Using the EZVIZ App, you can talk and react with only a simple tap
Easy to use but hard to tamper with.
In case the doorbell is forcibly removed, a sharp alarm will sound and a mobile alert will be instantly sent to you. What’s more, the DB2 Pro prohibits unauthorized use after theft, thanks to the account binding restriction.
Reduce video storage space and ease network loads.
The doorbell features the advanced H.265 video compression technology, achieving same or better video quality while reducing required bandwidth and storage space
*When the 24/7 recording mode is applied, the H.265 technology can reduce the video storage space and bandwidth by 50% as compared to H.264
We protect your data and privacy
Your data security and privacy is the cornerstone of every product we design. Data activities between the device and the EZVIZ Cloud is encrypted from end to end. Only you have the keys to decrypt your data
Safe, flexible storage options
You can insert a microSD card onto the indoor chime to save your recordings locally, without worrying about any data loss even if the doorbell is damaged or lost. You can also subscribe to EZVIZ CloudPlay for unlimited storage space and an additional layer of data protection
Specification
| Specifications | |
|---|---|
| Model | CS-DB2-A0-2C5WPFBR |
| Camera Parameters | |
| Image Sensor | 1/2.7" Progressive Scan CMOS (Supports low light sensitivity) |
| Lens | 2.0 mm @ F2.0, view angle: 176° (Diagonal) |
| Day & Night | IR-cut filter with auto-switching |
| Video Parameters | |
| Max. Resolution | 2544 × 1888 |
| DNR | 2D/3D DNR |
| Video Compression | H.265 / H.264 |
| Frame Rate | Max: 15fps; Self-Adaptive during network transmission |
| PIR Sensor | |
| Sensing Angle | 100° |
| Sending Distance | Max. 5 m (16.4 ft) |
| Sensitivity | User adjustable (High, Medium and Low Sensitivity) |
| Interface | |
| Audio Input | Built-in high-sensitivity microphone |
| Audio Output | Built-in high-power speaker |
| Reset button | Yes |
| Network Parameters | |
| Intelligent Alarm | PIR + human shape smart motion detection |
| Tamper Alarm | Sound and light anti-dismantling alarm (supports sending alerts to the smartphone) |
| Video Intercom | Long-distance video two way talk |
| Protocol | EZVIZ Cloud Proprietary Protocol |
| Interface Protocol | EZVIZ Cloud Proprietary Protocol |
| Wi-Fi Parameters | |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20 MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11Mbps, 11g :54Mbps, 11n :150Mbps |
| General | |
| Operating Conditions | -20°C to 50°C (-4°F to 122°F), Humidity 95% or less (non-condensing) |
| Ingress Protection Grade | IP65 |
| Weight | 241.35 g (8.5 oz) |
| Size | 150 × 58 × 32 mm (5.91 × 2.28 × 1.24 inch) |
| Battery Capacity | 5200mAh rechargeable lithium battery |
| Power Supply | DC5V±10% 2A |
| Power Consumption | Max. 2W |
| Chime | |
| Size | 100 × 55 × 35 mm (3.94 × 2.17 × 1.38 inch) |
| Power Supply | AC 110 ~ 240V |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
| Audio Output | 72 dB within 1 meter |
| Storage | Supports microSD card up to 256 GB |
| Weight | 120 g (4.2 oz) |
| In the box | |
| In the box | - DB2 Pro Video Doorbell |
| - Chime | |
| - Mounting Plates | |
| - Inclined Mounting Plates (2) | |
| - Screwdriver and Screw Kits (2) | |
| - Foam Sticker | |
| - Plate Foam | |
| - Drill Template | |
| - Pin | |
| -U-shaped Wire and Wire Connectors (3) | |
| - Power Cable | |
| - Quick Start Guide | |
| - Installation Guide | |
| - Regulatory Information | |
| Certifications | |
| Certifications | UL / CE / FCC / REACH / WEEE / RoHS |
