| Image Sensor |
5 MP CMOS |
| Signal System |
PAL/NTSC |
| Resolution |
2560 (H) × 1944 (V) |
| Frame Rate |
TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps CVI: 4MP@30fps, 4MP@25fps AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps CVBS: PAL/NTSC |
| Min. illumination |
0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time |
PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
| Lens |
2.8 mm, 3.6 mm, 6 mm Fixed lens |
| Field of View |
2.8 mm, horizontal FOV: 85.5°, vertical FOV: 63.7°, diagonal FOV: 110.7° 3.6 mm, horizontal FOV: 80.1°, vertical FOV: 63.7°, diagonal FOV: 105.9° 6 mm, horizontal FOV: 57.1°, vertical FOV: 43.1°, diagonal FOV: 72.5° |
| Lens Mount |
M12 |
| Day & Night |
ICR |
| WDR (Wide Dynamic Range) |
Digital WDR |
| Audio |
Built-in mic |
| Angle Adjustment |
Pan: 0 to 360°, Tilt: 0 to 75°, Rotation 0 to 360° |
| Image Mode |
STD/HIGH-SAT |
| AGC |
YES |
| Day/Night Mode |
Auto/Color/BW (Black and White) |
| White Balance |
Auto/Manual |
| AE (Auto Exposure) Mode |
DWDR/BLC/HLC/Global |
| Noise Reduction |
2D DNR |
| Language |
English |
| Function |
Brightness, Sharpness, Mirror, Smart IR |
| Video Output |
Switchable TVI/AHD/CVI/CVBS |
| Operation Conditions |
-40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing) |
| Power Supply |
12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. |
| Power Consumption |
Max. 3.7 W |
| Protection Level |
IP67 |
| Material |
Metal |
