Please note: This is the device of the Superior product line. Superior products are advanced versions of Jeweller devices. This product line is developed for projects. Only accredited Ajax Systems partners can sell, install, and administer Superior products.

The main feature of StreetSiren S DoubleDeck is the Brandplate
faceplate (sold separately). A security service provider can print
their logo and contact information on the front panel of the siren.

The siren becomes an additional marketing channel to reach new
customers like neighbours and visitors.

Jewellercommunication technology

• Up to 1,500 m of radio communication in an open space
• Data is encrypted throughout the transmission process
• Regular polling to display current device statuses

Event notifications

• Alarms of the systems devices
• Security status: armed/disarmed
• Door opening (Chime function)
• After alarm indication

Sabotage resistance

• Tamper alarm
• Device authentication to prevent spoofing
• Jamming detection
• Holding screw to secure the device on SmartBracket

Flawless autonomy

• Up to 5 years of battery life
• Low battery notifications
• Panasonic pre-installed battery

Compatibility

Hubs

• Hub Plus
• Hub 2 (2G)
• Hub 2 (4G)
• Hub 2 Plus
• Hub Hybrid (2G)
• Hub Hybrid (4G)

Range extenders

• ReX
• ReX 2

Communication with control panel

Jeweller communication

technology

Frequency bands: 868,0 — 868,6 MHz

Communication range: up to 1,500 m  *In an open space*

Alerts

Alarms: Acoustic

Delay When Entering/Leaving: Acoustic

Security mode change: Acoustic, LED

Security mode: LED

Door opening (Chime function): Acoustic

After-alarm indication: LED

Features

Types of notifications: Acoustic, LED

Alarm volume: from 85 to 113 dB

Alarm duration: from 3 s to 3 min

Piezoelectric buzzer frequency: 3.5 ± 0.5 kHz

Clip lock for the Brandplate
faceplate: (sold separately)

Power supply

Battery: 4 × CR123A

Battery life: up to 5 years

Manufacturer:Panasonic

Installation

Operating temperature range: from -25°С to +60°С

Operating humidity: up to 95%

Protection class: IP50

Enclosure

Colour: BLACK or WHITE

Dimensions: 200 × 200 × 55 mm

Weight: 571 g

Product code: 70227.61.BL1
