Image Sensor

1/1.8" CMOS

Signal System

PAL/NTSC

Min. Illumination

Color: 0.0008Lux@ (F1.6, AGC ON)

Shutter Time

1s to 1/100,000s

Day & Night

IR Cut Filter with Auto Switch

Optical Zoom

44X

Digital Zoom

16X

Lens

Focal Length

6mm~264mm

Zoom Speed

<5s

Field of View

Horizontal filed of view: 61.8° (w)~2.3° (t)
Vertical filed of view:36.3° (w)~1.3° (t)

Aperture Range

F1.6~F5.3

Focus Control

Auto/Manual

Iris Control

Auto

Close Focus Distance

1 m–3 m

Pan&Tilt

Pan Range

360°

Pan Speed

Pan Manual Speed: 0.1°~180°/s, Pan Preset Speed: 240°/s

Tilt Range

-16°~90° (Default -3°~90°)

Tilt Speed

Tilt Manual Speed: 0.1°~120°/s, Tilt Preset Speed: 180°/s

3D Position

Yes

Preset

500

Preset Accuracy

±0.3°

Cruise

16, up to 32 presets per cruise

Scan

8

Pattern

8, each with 600s memory or 1000 orders

Scheduled Task

Preset、Cruise、Scan、Pattern、Alarm output

Park Action

Yes

Power-off Memory

Yes

Preset  Freezing

Yes

Illuminator

IR LEDs

8

IR Distance

Up to 250m

IR Irradiation Angle

Adjustable by Zoom

White LEDs

2

Laser

N/A

Laser Distance

N/A

Compression Standard

Video Compression

S+265/H.265/H.264/M-JPEG

Video Bit Rate

32Kbps~16Mbps

Audio Compression

G.711A/G.711U/ADPCM_D/AAC_LC

Audio  Sampling Rate

8K～48Kbps


Max. Resolution

5MP (3072x1728)

Main Stream

PAL: 20fps (3072x1728), 25fps (2560x1440, 2304x1296), 50fps (1920x1080, 1280x960, 1280x720)
NTSC: 20fps (3072x1728), 30fps (2560x1440, 2304x1296), 60fps (1920x1080, 1280x960, 1280x720)

Sub Stream

PAL: 25fps (704x576, 704x288, 640x360, 352x288)
NTSC: 30fps (704x480, 704x240, 640x360, 352x240)

Third Stream

PAL: 25fps (704x576, 704x288, 352x288)
NTSC: 30fps (704x480, 704x240, 352x240)

BLC

Yes

HLC

Yes

WDR

True WDR

Image Stabilization

EIS

Fog

Digita

White Balance

Auto/Semi-auto/Manual/Sunny/Natural light/Warm light/Sodium lamp/Incandescent lamp/Locked white balance

AGC

Yes

Noise Reduction

2D/3D

ROI

7 Dynamic Areas for Both Main and Sub Stream, support 1 auto-tracking ROI

Picture Overlay

Yes

Privacy Mask

Yes

Smart Defog

Yes

Image Setting

Saturation, brightness, contrast, sharpness, adjustable by client software or web browser

Flip

Yes

OSD

16x16, 24x24,32x32, 48x48, 64x64,96x96, adaptable size, Letters such as Week, Date, Time, Total 5 Regions

Feature

Alarm Trigger

Harsh Voice Alarm, Motion Detection, Mask Alarm, Network Disable Alarm, IP Conflict, MAC Conflict Detection

Video Analytics

Tripwire, Double Tripwire, Perimeter, Object  Abandon, Object Lost, Loitering, Running, Parking, Heatmap, Crowd, People Counting, On Duty Detection, Safety Helmet Detection,Video Abnormal, Audio Abnormal

Early Warning(EW)

Yes

Auto-Tracking

Yes

Face Detection and Analytics

Operating Mode

Face capture, intelligent monitoring optional, default intelligent monitoring

Face Detection Performance

Detects up to 16 faces at the same scene

Face Exposure Brightness

Default 35, 1~100 brightness optional

Min. Face Pixel

Default 80, 26~3072optional

Network

Protocols

TCP/HTTP/MULTICAST/UPnP/PPPoE/DDNS/SIP/FTP/NTP/RTSP/ RTMP/SNMP/SMTP/802.1X/QoS/HTTPS/IPV4

System Compatibility

ONVIF (PROFILE S/T), SDK, CGI, P2P

ANR

Auto store video in SD card when NVR disconnected, and upload video to NVR when resumed connection (Only Support Tiandy ANR NVR)

Remote Connection

≤7

User/Host

Up to 32 users. 4 user levels

Web Version

web6

Interface

Communication Interface

1 RJ45 10M/100M self adaptive Ethernet port

Audio I/O

1/1

Alarm I/O

8/2

Built-In Speaker

Yes

Reset Button

Yes

On-board storage

Built-in Micro SD card slot, up to 128 GB

RS-485

Yes

BNC

Yes(Debugging use)

Wiper

Yes

Electronic Compass

N/A

GPS/BDS

N/A

General

Protection

IP66 , TVS 6000V lightning protection, surge protection and voltage transient protection

Web Client Language

16 languages
Simple Chinese/ Traditional Chinese/ English/ Spanish/ Korean/ Italian/ Turkish/ Russian/ Thai/ French/
Polish/ Dutch/ Hebraism/ Farsi/Arabic/ Vietnamese

Operating Conditions

-30°C~70°C (IR OFF),  -30°C~40°C (IR ON), 0-95%RH

Power Supply

AC24V±15%

Power Consumption

22W (IR OFF), 43W (IR ON)

Heater

N/A

Material

ADC12

Package/Boundary Dimensions

Φ310x500mm (Φ222x372mm)

Gross/Net Weight

9.0kg (5.5kg)
