·Metal+plastic housing
·S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG
·Color:0.0001Lux@(F1.0,AGC ON),B/W:0Lux with IR
·Built-in Mic, Built-in Speaker
·Support microSD/microSDHC/microSDXC card, up to 512 GB
·Support Smart surveillance
·Support Human/Vehicle Classification
·Operating Conditions -40℃~65℃(No turning on the light), Humidity 95% or less (no condensation)
·DC12V±25%,MAX 11.0W, POE 802.3at,MAX 12W
·IP67
|
Camera |
|
|
Image Sensor |
1/2.7"CMOS |
|
Min. Illumination |
Color:0.0001Lux@(F1.0,AGC ON),B/W:0Lux with IR |
|
Shutter Time |
1s~1/100000s |
|
WDR |
120dB |
|
S/N |
>46dB |
|
Angle Adjustment |
0~360°(P); 0~90°(T); 0~360°(R) |
|
Lens |
|
|
Lens Type |
Fixed focal lens |
|
Focal Length |
2.8mm |
|
Lens Mount |
M12 |
|
Aperture Range |
F1.0 |
|
Field of View |
180°(H)±10°; 65°(V)±5°; 191°±10° |
|
DORI Distance |
Detect:56m Observe:22m Recognize:11m Identify:5.6m |
|
Illuminator |
|
|
White LEDs |
3 |
|
Whitelight Distance |
15m |
|
Compression Standard |
|
|
Video Compression |
S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG |
|
Video Bit Rate |
32k~16Mbps |
|
Audio Compression |
G.711A/G.711U/ADPCM_D/AAC_LC |
|
Audio Sampling Rate |
8kHz/32kHz/48kHz |
|
Image |
|
|
Max. Resolution |
4640×1728@25fps |
|
Main Stream |
PAL:25fps(4640×1728, 4096×1520) NTSC:24fps(4640×1728, 4096×1520) |
|
Sub Stream |
PAL:25fps(1408×528) NTSC:24fps(1408×528) |
|
BLC |
Yes |
|
HLC |
Yes |
|
AGC |
Yes |
|
3D DNR |
Yes |
|
White Balance |
Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance |
|
ROI |
8 rectangular static areas |
|
OSD |
Overlay of additional characters in 5 regions, 2 lines, with a maximum of 127 characters or 42 Chinese characters per region; 16*16/32*32/48*48/64*64/96*96/128*128 |
|
Picture Overlay |
1*200x200 size BMP 24 color bit image overlay |
|
Privacy Mask |
4 black static areas |
|
Defog |
Yes |
|
Feature |
|
|
Alarm Trigger |
Motion Detection; Mask Alarm; Voltage Alarm; Disk Full; Disk R/W Error; IP Address Conflict; MAC Address Conflict; FTP Server Exception ; Event Input, Event Output |
|
Linkage Method |
send email; trigger sound; trigger warmlight; trigger recording; trigger capture; notify surveillance center |
|
Video Analytics |
Human/Vehicle Classification; Tripwire; Perimeter; Video Abnormal; Audio Abnormal |
|
Rules of behavior analyse in 1 scene |
8 |
|
Early Warning(EW) |
Early Warning(EW) |
|
Network |
|
|
ANR |
Yes |
|
Protocols |
HTTP; HTTPS; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMP; DHCP; DNS; DDNS; Easy DDNS; NTP; SMTP; SSL; 802.1X; QoS; IPv4; IPv6; PPPOE; SSH; Unicast; Multicast; RTCP; ARP; RTP; SRTP; RTSP; FTP; SFTP; NAS |
|
System Compatibility |
ONVIF Profile S/T/G/M; CGI; Milestone; RTMP |
|
Remote Connection |
≤7 |
|
Client |
Easy7 Smart Client |
|
Moblie Client |
EasyLive Plus |
|
Interface |
|
|
Communication Interface |
1*RJ-45,10/100 Mbps self-adaptive Ethernet port |
|
Audio I/O |
1; 1 |
|
Alarm I/O |
1-ch,TTL input,3mA,3.3VDC; 1-ch,TTL output,30mA,12VDC |
|
Reset Button |
Yes |
|
On-board storage |
Support microSD/microSDHC/microSDXC card, up to 512 GB |
|
RTC |
Yes |
|
General |
|
|
Web Client Language |
19 languages Simple Chinese/Traditional Chinese/English/Spanish/Korean/Italian/Turkish/Russian/Thai/French/Polish/Dutch/Hebrew/Arabic/Vietnamese/German/Ukrainian/Portuguese/Albanian |
|
Operating Temperature |
-40℃~65℃(No turning on the light) |
|
Operating Humidity |
Humidity 95% or less (no condensation) |
|
Storage Temperature |
-40℃~65℃ |
|
Storage Humidity |
Humidity 95% or less (no condensation) |
|
Power Supply |
DC12V±25%,MAX 11.0W; POE 802.3at,MAX 12W |
|
Protection |
Surge4000V; ESD6000V; IP67 |
|
Boundary Dimensions |
294(L)116(W)72(H)mm |
|
Package Dimensions |
360(L)150(W)170(H)mm |
|
GrossWeight |
1.1kg |
| Weight | 4.0000 kg |
|---|---|
| color | White |
| Type | |
| Megapixel | |
| Camera Type | Panoramic |
| Night Vision | Infrared |
| Weatherproof | IP67 |
| Signal Type | IP |
| Lens Size |
