Image Sensor

1/2.8" CMOS

Signal System

PAL/NTSC

Min. Illumination

Color:0.0008Lux@(F1.6,AGC ON),B/W:0Lux with IR

Shutter Time

1s to 1/100,000s

Day & Night

Dual IR Cut Filter with Auto Switch

WDR

120dB

Angle Adjustment

Bracket,pan 0~360°,tilt 0~75°,roate 0~360°

Lens

Lens Type

Fixed

Focus

2.8mm/4mm

Lens Mount

M12

Aperture

F1.6,Fixed

FOV

Horizontal field of view:100.6°(2.8mm)/83.3°(4mm)；Vertical field of view:56.5°(2.8mm)/46.8°(4mm)

Illuminator

IR LEDs

2

IR Range

Up to 50m

Wavelength

850nm

White LEDs/Warmlights

2

Compression Standard

Video Compression

S+265/H.265/H.264

Video Bit Rate

32Kbps~6Mbps

Audio Compression

G.711A/G.711U/ADPCM_D_D

Audio Bit Rate

8K,32K,48Kbps


Max. Resolution

1920x1080

Main Stream

PAL:25fps(1920x1080,1280x720,704x576,640x480)

NTSC:30fps(1920x1080,1280x720,704x480,640x480)

Sub Stream

PAL:25fps(704x576,704x288,640x360,352x288)

NTSC:30fps(704x480,704x240,640x360,352x240)

Third Stream

N/A

Image Setting

Saturation,brightness,contrast,sharpness,adjustable by client software or web browser

Image Enhancement

BLC/3D DNR/HLC

ROI

8

OSD

16x16,32x32,48x48,adaptable size,Letters Such as Week,Date,Time,Total 1 Regions

Picture Overlay

N/A

Privacy Mask

Yes,4 regions

Smart Defog

Yes

Feature

Alarm Trigger

Motion Detection,Mask Alarm,IP Address Conflict

Video Analytics

Tripwire,Perimeter

Early Warning(EW)

N/A

Network

ANR

Yes(Only Support Tiandy ANR NVR)

Protocols

HTTP,HTTPS,TCP/IP,UDP,UPnP,ICMP,DHCP,DNS,DDNS,Easy ddns,NTP,IPv4

System Compatibility

ONVIF(PROFILE S/T/G),SDK,CGI,Milestone,P2P(Mutually exclusive with Profile G)

Remote Connection

2

Client

Easy7,EasyLive

Web Version

Web6

Interface

Communication Interface

1 RJ45 10M/ 100M self adaptive Ethernet port

Audio I/O

Mic in

Alarm I/O

N/A

Speaker

N/A

Reset Button

Yes

On-board storage

Built-in MicroSD card slot,up to 512 GB

General

Web Client Language

17 languages
Chinese Simplified/English/Chinese Traditional/Spanish/Italian/Korean/Turkish/Russian/Thai Chinese/Polish/French/Dutch/Hebrew/Vietnamese/Arabic/German/Ukrainian

Operating Conditions

-35℃~60℃ ,0～95% RH

Power Supply

DC 12V±25%,PoE(802.3af)

Power Consumption

MAX:6W(12V) MAX:8W(PoE)

Protection

IP67

Heater

N/A

Dimensions

160.8x68x74.5mm(6.33x2.68x2.93inch)

GrossWeight

Metal+Plastic:0.47Kg(1.03lb)

NetWeight

Metal+Plastic:0.31Kg(0.68lb)
