Image Sensor

1/2.8"   CMOS

Signal System

PAL/NTSC

Min. Illumination

Color:0.002Lux@(F1.6,AGC   ON),B/W:0Lux with IR

Shutter Time

1s to 1/100,000s

Day & Night

Dual IR Cut   Filter with Auto Switch

WDR

120dB

Angle Adjustment

Bracket,pan   0~360°,tilt 0~75°,roate 0~360°

Lens

Lens Type

Fixed

Focus

2.8mm/4mm

Lens Mount

M12

Aperture

F1.6

FOV

Horizontal field of view:104.2°(2.8mm)/88.7°(4mm)；Vertical field of view:58.8°(2.8mm)/46.8°(4mm)

Illuminator

IR LEDs

2

IR Range

Up to 50m

Wavelength

850nm

White LEDs/Warmlights

N/A

Compression Standard

Video Compression

S+265/H.265/H.264/M-JPEG

Video Bit Rate

32Kbps~16Mbps

Audio Compression

G.711A/G.711U/ADPCM_D/AAC

Audio Bit Rate

8K,32K,48Kbps


Max. Resolution

2880x1620

Main Stream

PAL:25fps(2880x1620,2688x1520,2560x1440,2304x1296)50fps(1920x1080,1280x720)

NTSC:30fps(2880x1620,2688x1520,2560x1440,2304x1296)60fps(1920x1080,1280x720)

Sub Stream

PAL:25fps(704x576,704x288,640x360,352x288)

NTSC:30fps(704x480,704x240,640x360,352x240)

Third Stream

PAL:25fps(1920x1080,1280x720,704x576,704x288,640x360,352x288)
  NTSC:30fps(1920x1080,1280x720,704x480,704x240,640x360,352x240)

Image Setting

Saturation,brightness,contrast,sharpness,adjustable   by client software or web browser

Image Enhancement

BLC/3D DNR/HLC/Corridor Format

ROI

Support 8   fixed regions of coding

OSD

16x16,32x32,48x48,64x64,adaptable size,Letters Such as   Week,Date,Time,Total 5 Regions

Picture Overlay

Yes

Privacy Mask

Yes,4 regions

Smart Defog

Yes

Feature

Alarm Trigger

Event Input,Event Output,Motion Detection,Mask   Alarm,Disk Full,Disk R/W Error,IP Address Conflict,MAC Address Conflict,FTP   Server Exception,Voltage Abnormal,Video Abnormal,Audio Abnorma

Video Analytics

Tripwire,Double   Tripwire,Perimeter,Object Abandon,Object   Lost,Loitering,Running,Parking,Crowed, People Counting,On Duty   Detection,Heatmap,Face Capture,Safety Helmet Detection,Human/Vehicle   Classification

Early Warning(EW)

N/A

Network

ANR

Yes(Only Support Tiandy ANR NVR)

Protocols

RTSP,SRTP,HTTP,HTTPS,TCP/IP,UDP,UPnP,ICMP,IGMP,SNMP,DHCP,DNS,DDNS,Easy   DDNS,NTP,SMTP,802.1,QoS,IPv4,IPv6,PPPOE,SSH,Multicast,RTCP,ARP,FTP.NFS

System Compatibility

ONVIF(PROFILE S/T/G),SDK,CGI,Milestone,P2P

Remote Connection

2

Client

Easy7,EasyLive

Web Version

Web6

Interface

Communication Interface

1 RJ45 10M/ 100M self adaptive Ethernet port

Audio I/O

1/1,Mic in

Alarm I/O

1/1

Speaker

N/A

Reset Button

Yes

On-board storage

Built-in MicroSD card slot,up to 512 GB

General

Web Client Language

17 languages
  Simplified Chinese/English/Traditional   Chinese/Spanish/Italian/Korean/Turkish/Russian/Thai/   Polish/French/Dutch/Hebrew/Persian/Vietnamese/Arabic/German/Ukrainian

Operating Conditions

-40℃～65℃ ,0～95% RH

Power Supply

DC12V±25%/PoE

Power Consumption

MAX:6W(12V)   MAX:7W(PoE)

Protection

IP67

Heater

N/A

Dimensions

160.8x68x74.5mm(6.33x2.68x2.93inch)

GrossWeight

0.65Kg(1.36lb)

NetWeight

0.52Kg(1.14lb)
