Image Sensor

1/2.8" CMOS

Signal System

PAL/NTSC

Min.   Illumination

Color:0.003Lux@(F1.6,AGC ON),B/W:0Lux with IR

Shutter Time

1s to   1/100,000s

Day & Night

Dual IR Cut Filter with Auto Switch

WDR

120dB

Angle   Adjustment

Bracket,pan 0~360°,tilt 0~75°,roate 0~360°

Lens

Lens Type

Fixed

Focus

2.8mm/4mm

Lens Mount

M12

Aperture

F1.6,Fixed

FOV

Horizontal   field of view:96°(2.8mm)/84.8°(4mm)

Illuminator

IR LEDs

2

IR Range

Up to 50m

Wavelength

850nm

White   LEDs/Warmlights

N/A

Compression   Standard

Video   Compression

S+265/H.265/H.264/M-JPEG

Video Bit Rate

32Kbps~16Mbps

Audio   Compression

G.711A/G.711U/ADPCM_D/AAC

Audio Bit Rate

8K,32K,48Kbps


Max. Resolution

3840x2160

Main Stream

PAL:25fps(3840x2160,3072x2048),25fps(2560x1440,2304x1296,1920x1080,1280x720)

NTSC:30fps(3840x2160,3072x2048),30fps(2560x1440,2304x1296,1920x1080,1280x720)

Sub Stream

PAL:25fps(704x576,704x288,640x480,352x288)

NTSC:30fps(704x480,704x240,640x480,352x240)

Third Stream

PAL:25fps(704x576,704x288,640x360,352x288)
  NTSC:30fps(704x480,704x240,640x360,352x240)

Image Setting

Saturation,brightness,contrast,sharpness,adjustable   by client software or web browser

Image   Enhancement

BLC/3D   DNR/HLC/Corridor Format

ROI

Support 8 fixed regions of coding

OSD

16x16,24x24,32x32,48x48,64x64,96x96,adaptable   size,Letters Such as Week,Date,Time,Total 8 Regions

Picture Overlay

Yes

Privacy Mask

Yes,4 regions

Smart Defog

Yes

Feature

Alarm Trigger

Event   Input,Event Output,Motion Detection,Mask Alarm,Disk Full,Disk R/W Error,IP   Address
  Conflict,MAC Address Conflict,FTP Server Exception,Video Abnormal,Audio   Abnormal

Video Analytics

Tripwire,Double Tripwire,Perimeter,Object   Abandon,Object Lost,Loitering,Running,Parking,Crowed, People Counting,On Duty

Detection,Heatmap,Safety Helmet Detection,Human/Vehicle Classification

Early   Warning(EW)

N/A

Network

ANR

Yes(Only   Support Tiandy ANR NVR)

Protocols

IPv4,IPv6,IGMP,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTP,RTSP,RTCP,DNS,DDNS,NTP,FTP,UPnP,HTTP,HTTPS,SMTP,802.1x,SNMP,SSL,

QoS,Telnet,RTMP;SFTP;Multicast;NFS

System   Compatibility

ONVIF(PROFILE   S/T/G/M),SDK,Milestone,CGI,P2P

Remote   Connection

2

Client

Easy7,EasyLive

Web Version

Web6

Interface

Communication   Interface

1 RJ45 10M/   100M self adaptive Ethernet port

Audio I/O

1/1,Mic in

Alarm I/O

1/1

Speaker

N/A

Reset Button

Yes

On-board   storage

Built-in   MicroSD card slot,up to 512 GB

General

Web Client   Language

17 languages
  English,Russian,Spanish,Korean,Italian,Turkish,Simple Chinese,Traditional   Chinese,Thai,French,Polish,Dutch,Hebraism,Arabic,Vietnamese,Ukrainian,German

Operating   Conditions

-40℃～65℃,0～95% RH

Power Supply

DC12V±25%/PoE

Power   Consumption

MAX:6W(12V) MAX:7W(PoE)

Protection

IP67

Heater

N/A

Dimensions

160.8x68x68mm(6.33x2.68x2.68inch)

GrossWeight

0.65Kg(1.43lb)

NetWeight

0.50Kg(1.10lb)
